Union Special 81300B2

81300

Heavy Duty Two Needle High Throw Safety Stitch Bag Making Machine, Seam Width 24mm, Top and Bottom Feed, Pneum. Presser Foot Lifter, for Geotextile

Heavy duty two needle, four thread safety stitch machine with high needle throw. With top and bottom feed for matched seams on heavy geotextile as also bag fabric. Needle distance 5 mm, overedge seam width 19 mm, seam width overall 24 mm. With guide for filler cord from the top and / or below for sealing the needle punctures of the left needle. Electro-pneumatically operated presser foot and upper feed dog lifter. Pneumatic presser foot spring.

Type No. 81300B2
Series 81300
Application Geotextile
Stitches/min. 1.400
Stitch range 6.00mm – 13.00mm
Standard setting 10.00mm
Capacity under presser foot 16.00mm
Thread chain and tape cutter (Ohne)
Bag material Felt Woven fabric Other
Lubrication Manual lubrication
Standard needle 9853GA430/172
Stitch types (401.502)
Feed type Top and bottom feed
Closures Plain closure
Branche Geologic materials
Material thickness 100-200 g/mē above 200 g/mē
Needles 2
Thread 2500-4000 Den
Installation Table assembly
Color Olivegreen
Packing mass (L/W/H) 46cm/47cm/61cm
Net weight 48kg
Gross weight 53kg
