Union Special 3100A

3100A

Portable Singel Thread Bag Closing Machine, Protection Class I

Portable single thread bag closing machine with fan cooled, advanced design electric motor.
For efficient and easy closing of bags.
Light weight, well balanced machine permits effortless operation.
Motor housing and handle made of ABS plastic.
Power cable 5 m long.

Type No. 3100A
Series 3100
Application Säcke zunähen
Bags per hour 200
Stitches/min. 1.500 – 1.700
Stitch range 8.00mm
Standard setting 8.00mm
Capacity under presser foot 5.00mm
Thread chain and tape cutter Continuously driven nibbler knive
Handling Portable, Suspended
Class Standard
Sewing capacity on paper 12 plies
Bag material Jute
PP woven-fabric
PP laminated woven fabric
PE-material
Burlap bag
Paper
Lubrication Manual lubrication
Protection classes Protection class I
Standard needle 9858G200/080
Start-stop Hand switch
Stitch types 101
Feed type Bottom feed
Closures Plain closure
Voltage 230V AC
Color Black
Packing mass (L/W/H) 39cm/21cm/43cm
Net weight 4kg
Gross weight 6kg
