Union Special 2200MR
Rechargeable Battery Operated Portable Bag Closer for Closing Bags and Sewing Geo Fabrics
Rechargeable battery operated, portable sewing machine with top feed. Extra heavy sewing parts. For operation in locations where no electricity is available. For joining geotextile support fabrics at construction sites, for closing bags made of paper, jute, cotton and plastic, in agricultural areas, areas endangered by floods etc. Powered by a 24 volt, 120 watt DC-motor. Power supply by lithium ion plug-in rechargeable battery at the motor. Production capability with full charged batteres approx. 600-800 bags, depending upon type of material, number of plies, stitch length and width of bags. Battery charger and spare rechargeable battery included. Charging time max. 90 minutes. Recommended extra: Additional battery, part No. 90197.
| Type No. | 2200MR |
|---|---|
| Series | 2200 |
| Application | Geotextile Säcke zunähen |
| Bags per hour | 800 |
| Stitches/min. | 700 – 1.500 |
| Stitch range | 3.00mm – 9.00mm |
| Standard setting | 8.00mm |
| Capacity under presser foot | 9.00mm |
| Thread chain and tape cutter | Continuously driven nibbler knive |
| Handling | Portable, Suspended |
| Class | Standard |
| Sewing capacity on paper | 24 plies |
| Bag material | Jute PP woven-fabric PE-material Burlap bag Paper |
| Lubrication | Manual lubrication |
| Protection classes | Protection class III |
| Standard needle | 9854G230/090 |
| Start-stop | Hand switch |
| Stitch types | 401 |
| Feed type | Top and bottom feed |
| Closures | Plain closure Fold over closure |
| Voltage | 24V DC |
| Color | White |
| Net weight | – |
